3D Printed Waste

In 2015 the construction industry in Metro Vancouver produced approximately 218 000 tonnes of waste wood. This waste stream included 29% untreated dimensional lumber, 25% composite wood products, and 14% shredded wood (note 1).

Printing Wood

HiLo Lab is actively exploring the use of wood waste in additive fabrication. We’re developing a variable form of 3D printing tailored to fibrous materials, enabling more efficient production of architectural assemblies using diverted wood waste.

The potential is enormous. In British Columbia and beyond, wood off-cuts, sawdust, chips, and breakage form a massive, and largely untapped, material stream. Turning this waste into a printable medium could reduce landfill volumes, expand markets for the timber industry, and open new territory for sustainable design. Our aim is to position designers at the center of this opportunity. By developing new material workflows and architectural typologies for printed wood composites, we hope to drive innovation that is both ecological and expressive.

note 1:  http://www.metrovancouver.org/services/solid-waste/SolidWastePublications/2015DLCWasteCompositionMonitoring.pdf

Process

For this set of tests, our printable mixture consisted of approximately 80% wood waste combined with a powdered urea-formaldehyde adhesive. After extrusion, forms are cured in a low-cost, makeshift autoclave at 85°C for 90 minutes. The result is a hard, finished product—dense, strong, and dimensionally stable.

We use two custom fabrication systems to accomplish our objectives. A progressive cavity pump, 3D printed in-house and driven by a NEMA 17 stepper motor, enables continuous flow without compacting the material or altering its moisture content. Custom nozzles allow for varied print geometries. Second, a modified delta-style 3D printer built by the team enables extrusion of clay, pastes, and experimental mixtures including our wood-based media.

This is early-stage work with long-term implications. We are not just asking what waste can do, we’re asking what it can become.

CONTRIBUTORS: SALA HiLo Team: Stuart Lodge, Rachel Killoh, Josh Potvin, Blair Satterfield.
Special thanks to Dr. Chad Sinclair

Fig 1: A range of mixes were produced, compacted into rectangular forms and allowed to dry. These samples were tested for strength, ability to maintain shape, and viscosity.

Fig 2: The printed material retains its shape in its ‘wet’ form. It has the ability to cling to both itself and the material its being printed on. These are important characteristics for large 3D printers.

Fig 3: We designed and printed a Monieau pump to move material to the print head. Driven by a NEMA 17 stepper motor, the part is easily swapped, allows the printer to push material without water separation, and can be fitted with custom nozzles.

Fig 4: The delta 3D-printer in operation. Here it is printing a clay column.
